yuchai300qianwa-800-800

800KW 1000KVA

Guangxi Yuchai Machinery Group currently has six core business segments: diesel engine, construction machinery, special purpose vehicles, automobile chemical industry, auto parts and logistics machinery. The production capacity of diesel engine is 600,000 units per year and that of small construction machinery is 10,000 units per year. Is the world's largest independent diesel engine production base, known as the "Green power capital of China". New hong source yuchai series generator set to yuchai engine as the motive force, independent research and development production of yuchai diesel generating sets, production to backup power for the demand of intelligent environmentally friendly diesel generating sets and related products, products include: standard diesel generating sets, refurbished units, container type units, mobile power station, trailers, and intelligent control system.

Inquire
yuchai300qianwa-800-800
Model:800KW 1000KVA Brand:Yuchai

Product Description

Yuchai 800 KW diesel generator set

Generator type

XHY-800

Weight

7900KG

Out power

800KW/1000KVA

Dimensions

4600×1800×2500

Power factor

COSΦ=0.8(Lag)

Voltage

400/230

Current Amp.(PRP)

1440A

Frequency

50Hz





[Engine]parameters

Engine type

YC6C1220L-D31

Coolant capacity

/

Speed

1500RPM

Cylinders

6cylinderlineFour stroke

Power Max.

815/897KW

Engine cooling mode

Closed circulating water cooling

Fuel consumption

≤195g/kw.h

Speed control system

Electronic speed regulation

Oil capacity

180L

Start model

DC 24V Electrical start

Bore×stroke

200×210 mm

Compression ratio

15:01

Engine filtration system

Dry air filter, fuel filter, oil filter





[Alternator]parameters

Producers

Shandong xinhongyuan

Steady rate of change of frequency

Better than 5%

Model

XHY800F

No-load voltage adjustment range

≥95%—105%

Voltage control mode

AVR

Insulation class/protection class

H/IP22

Voltage regulation ratio

±1%

Excitation mode

Brushless excitation

Rated voltage/frequency/power factor/connection mode

400V/230V,50Hz,0.8lag3p4w
